WAVERAv1.2

Everything here processes real sound. Press Play for the built-in demo loop, drop in your own track, or paste a YouTube link and capture its tab. Use headphones, then try A / B: the bypass is loudness-matched, so you hear the processing, not extra volume.

creative osWAVERAv1.2
Engine idle
Built-in synth loop, 112 BPM. Or drop an audio file anywhere on the console.
Opens the link in a new tab. Then click Capture a tab, pick that tab, and tick Share tab audio. The tab goes quiet and you hear it through WAVERA. Desktop Chrome or Edge only.

Reference: the colour stages (Clarity, Warmth, Punch, Stereo, Flavor) are off. EQ, Night and the limiter stay as set. Headphone and room correction come with the Windows app.

— LUFSin
Press Play
Intensity15%stopped
Sample peak — dBFS
Correlation —
PLR — dB
— LUFSout
Signal chain · click a module to bypass it

Presets

In the Windows app these attach to apps automatically: foobar2000 gets Music, REAPER gets Mix check.

Tray mode

15%music
The DFX mini-player, kept and modernised. These bars are live too.

What each control really does

ControlDSP in this demo
Bass / Body / Presence / AirBiquad EQ. Each character switch changes the filter: thick = 110 Hz shelf, punchy = 70 Hz peak; gentle = wide 450 Hz peak, warm = 260 Hz shelf; forward = 2.5 kHz peak, smooth = wide 4 kHz peak; silk = 11 kHz shelf, sparkle = 9 kHz peak.
ClarityParallel harmonic exciter: content above 3.5 kHz is saturated, high-passed again and blended back in.
WarmthTilt: low shelf up at 220 Hz, high shelf down at 4 kHz.
PunchCompressor with a 25 ms attack, so transients pass before the body is held down.
Space / DialogueMid/side matrix: Space scales the side signal, Dialogue lifts the mid and adds a 2.2 kHz presence peak.
FlavorWaveshaper at 4× oversampling. Tape = symmetric soft clip, Tube = asymmetric (even harmonics), Vinyl = soft clip plus a 12 kHz roll-off.
IntensityScales every EQ gain and knob amount together. Starts at a gentle 15% so nobody gets a sudden jump in level; 70% is each preset at full design strength. Changing preset never changes intensity.
A / BMomentary loudness (BS.1770 K-weighting, approximate) is measured on the dry and processed signals, and the bypass is gained to match.
LimiterFast compressor with a −1.5 dB threshold. It's a sample-peak safety net, not a true-peak limiter yet.
Windows appSystem-wide capture through a virtual audio device, per-app routing, ASIO out.
Windows appHeadphone targets (AutoEQ, REW imports), room-correction convolution, true-peak limiting.
Windows appNeural restore and stem separation on the NPU, VST3 hosting, 64-bit engine.
